SMHC50-D

  • SANY 50T Crawler-based Electric material handling machine has been widely used in Steel Plants, Log Stacking yards to load or stack steel scrap and bulk cargoes. Driven by a motor saves 50% cost compared to diesel-operated MHC.
Sany SMHC50-D Electric Crawler Material Handler Crane

Weight:

50 T

Vertical Height & Depth:

+12 m & -1.5m

Horizontal Reach:

10.5m-Op1, 13.5m-Op2

Engine:

Chang Diantou

Transmission:

DANA / Zhongnan

Boom-Stick:

11.5m Arm(7m B+4.5m

Grabber Options:

Orange Peel, Clam S

Theoretical Load at Max. Radius:

5.9 T Inc Grabber Wt

About SMHC50-D

Efficient and Sustainable Material Handling Solution

SANY 50T Crawler-based Electric material handling machine has been widely used in Steel Plants, Log Stacking yards to load or stack steel scrap and bulk cargoes. Driven by a motor saves 50% cost compared to diesel-operated MHC. It uses multiple in-house developed technologies in Energy saving and control, Hydraulic linkage, Anti-Rollover Protection, Malfunction Automatic Detection and Real-time data display to backup performance.

features-new

FEATURES

Highly Efficient

Highly Efficient

  • Turning cycle in one minute: 8 times
  • Minimum working cycle: 30 seconds
  • Maximum grab capacity: 5 m³
  • Loading and unloading efficiency: 520 t/h
  • Ability to load 13 units of 40-ton trucks within one hour
  • 10% more efficient than competitors

Energy Saving

Energy Saving

  • 10% fuel consumption savings with Kawasaki positive hydraulic system and Sany DOMCS control system
  • Advanced structure design: lighter and stronger
  • Smart controller adjusts engine speed and output based on real-time capacity

Dynamic Anti-Rollover Protection Technology

Dynamic Anti-Rollover Protection Technology

  • Adopts Intelligent Control technology
  • Detects real-time working parameters of the equipment
  • Automatically adjusts operating status under dangerous conditions to prevent rollover
  • Ensures safe and worry-free operation

Grabber Options

Grabber Options

  • Plum Blossom Grab: Capacity: 0.8 & 1 m³
  • Suitable for waste steel handling
  • Efficiency: 240-320 t/hour
  • Double Shell Grab: Capacity: 1.5 to 5 m³
  • Suitable for grains, coal, fertilizer, feedstuff, sand, gravel, and iron ore
  • Log Grab: 2m²
  • Electromagnetic Grab: Diameter options: 1.1m & 1.3m

Smart Features

Smart Features

  • 4 Directions Camera Monitor System with 7-inch Display Screen
  • Additional camera equipped in stick front
  • 3m Reverse Camera System with Radar
  • Camera records feature (includes 8 GB flash drive)
  • Weighting System
  • Central lubrication in upper carriage (excluding grab)
